Highlights:
1. Supports for Mercedes Benz All Keys Lost, faster calculate password
2. supports IM608 or IM508 with XP400
3. Used for faster Mercedes ECU data and EIS password calculation
4. Mercedes DAS3 can EIS / EZS lost all keys
5. Reduced reading time of W204 ECU data & W207 EIS by over 85%
6. No need to remove and reinsert the keys for W221 & W164 after 2009 models
Highlights:
1. Supports for Mercedes Benz All Keys Lost, faster calculate password
2. Supports IM608 or IM508 with XP400
3. Used for Faster Mercedes ECU data and EIS password calculation
4. Mercedes DAS3 can EIS / EZS all keys lost
5. Reduced reading time of W204 ECU data & W207 EIS by over 85%
6. No need to remove and reinsert the keys for W221 & W164 after 2009 models
Description:
The G-BOX3 realizes quick mode on vehicle and bank when all buttons of the for Mercedes-Benz vehicles with ths DAS3 EIS / EZS are lost. The use of the G-BOX3 reduces the time needed and eliminates the process of insertion and removal.
The G-BOX3 can read and access most engines manufactured by Bosxx including EDS / MEx17 series engines used in for BMW and for VW vehicles. This ability supports the ability to perform adaptions when all keys are lost and the engine is replaced.
The G-BOX3 is compatible with the Autel advanced diagnostic tablets supporting IMMO and key programming functions.
Less time, safer
1. Support fast mode on Vehicle and bank when all buttons of the for Mercedes-Benz vehicles with the Das3 EIS / EZS are lost
2. Read and write BosxxEngine ECU on F Classis from for BMW and MQB from for VW
3. With the Autel advanced Diagnostic Tablets support IMMO and Key programming functions
Product Display:
1. DC Port - Provides + 12V DC power supply.
2. CAN-H Port - Universal CAN bus interface, connects with OBDII Pin6
3. K1 Port - Universal K-Line interface, connects with OBDII Pin1
4. Status Indicator - Shows the current operating status
5. Relay Ports - Connect with dedicated relays Cable
6. + 12V Power Port - Universal power input / output port
7. OBDII Male Connector To the vehicle OBDII directly or via a dedicated extension cable
8. OBDII Female Connector To the main cable of Autel diagnostic tablet
9. CAN-L Port - Universal CAN Bus interface, connects to OBDII Pin14
10. K7 Port - Universal K-Line interface, connects to OBDII Pin7
11. GND Port - Universal power input / output port
12. DB15 Port - Used with dedicated DB15 cables for reading and writing several types of ECUs
How to Make the G-BOX3 Work?
1. OBDII Operation when all buttons of the for Mercedes-Benz vehicle are lost?
Use OBDII access on for Mercedes Benz vehicles manufactured after 2009 with W204, W207, W216 and W164 EISs
Conection steps:
1). Connect the G-BOX3 to vehicle OBDII
2). Remove the fuse from the vehicle EIS. Connect the Relay ports to the fuse with the supplied fuse cable.?
3). If the vehicle has an ELV, connect the K7 port and ELV connector with the supplied K-Line cable?
4). Connect the G-BOX3 to the Autel Diagnostic Tablet.?
2. Desktop Operation When All Buttons of the Mercedes-Benz Vehicle are Lost
Use this method for all for Mercedes-Benz vehicle EISs supported by Autel diagnostic tablets supporting IMMO and Key programming functions
Conntection steps:
1). Connect the G-BOX3 to the for Mercedes-Benz EIS with the supplied DB15 cable
2). Connect to the DC Port of G-BOX3 with a power supply (DC 12V)
3). Connect the G-BOX3 to the Autel Diagnostic Tablet
3. Read Engine Password Operation on the Bank
Use this method for Bosxx ECUs supported by Autel Diagnostic Tablets support IMMO and Key Programming Functions?
Connection steps:
1). Connect the G-BOX3 to Autel diagnose tablet
2). Connect the G-BOX3 to engine ECU
3). Connect to the DC port of G-BOX3 with a power supply (DC 12V)
Package List:
1pc x Autel G-BOX3
1pc x DB15 Cable
1pc x K-Line Cable
1pc x FuseCable2pcs
x Fuse (5A)2pcs x
Clamp Cable
1pc x OBDII Extension Cable
1pc x Quick Reference Guide
